2003-2008 TOYOTA COROLLA
99-8204
DASH DISASSEMBLY
Disconnect the negative battery terminal to prevent an accidental short circuit. Unsnap the
gear shifter trim bezel and remove. Remove the center climate control knob and (1) Phillips
screw exposed. Unclip the climate control bezel/pocket assembly and remove. Remove (4)
10 mm bolts from the bottom of the factory head unit. Remove the factory head unit/trim
bezel assembly and disconnect the wiring. Unclip the bezel from the head unit and remove
the unit.
