2
DASH DISASSEMBLY
1. Unclip and remove the entire panel
around the radio from the instrument
cluster to the passenger side of the
dash including the clock and A/C vents.
(Figure A)
Note: Start on the passenger side with
the glove box open.
2. Remove (4) 10mm bolts securing the
factory radio and remove it.
(Figure B)
3. Remove the (4) yellow panel clips from
the factory radio.
Continue to Kit Assembly
(Figure A) (Figure B)
