Metra Electronics 99-9105 - Kit Assembly; DIN Radio Installation

2
99-9105
KIT ASSEMBLY
Snap the pocket into the Radio
Housing until secure.
(Figure C)
3
Slide the DIN cage into the Radio
Housing and secure by bending
the metal locking tabs down.
(Figure A)
1
Slide the aftermarket radio into the
cage and secure. (Figure B)
2
DIN RADIO PROVISION WITH POCKET
A
B
C
Continue to final assembly.
