Metra Electronics 99-9105 - ISO Radio Installation

3
99-9105
KIT ASSEMBLY
Slide the radio into the radio
opening until the side clips
engage.
(Figure B)
2
Snap the ISO Trim Plate into the
Radio Housing.
(Figure C)
3
Snap the pocket into the radio
housing.
(Figure C)
4
Mount the ISO Brackets to the
radio with the screws supplied
with the unit. (Figure A)
1
ISO RADIO PROVISION WITH POCKET
A
B
C
Continue to final assembly.
