99-9302 DASH DISASSEMBLY
BMW Mini Cooper/Cooper S 2002-2007
D
E
F
G
2
Remove (1) Phillips scew from each
cup holder. (
Figure D)
5
Carefully pry up mirror adjustment
switch panel and remove (2) Phillips
screws. (
Figure E)
6
Slide cup holder/gear shift assembly
toward rear of car and carefully
remove side rail trims.
(Figure F)
7
Remove (4) Phillip screws securing
radio. Pull out radio, disconnect and
remove.
(Figure G)
8
To Next Page
