99-9302 KIT ASSEMBLY
3
A
B
DIN MOUNT RADIO PROVISION
Slide the DIN cage into the radio open-
ing of the Radio Housing and secure by
bending the metal locking tabs out-
ward.
(Figure A)
1
Slide the aftermarket radio unit into the
cage until it snaps into place.
(Figure B)
2
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
