6
(Figure S)
15. Looking in the glovebox cavity up high,
remove (2) 13mm screws securing the
back of the passenger side airbag.
(Figure S))
16. Unclip and slightly release the airbag
panel, just enough to expose (3) Phillips
screws securing the passenger side dash
panel. Remove the (3) screws.
(Figures T, U)
DASH DISASSEMBLY
(Figure U)
(Figure T) (Figure V)
17. Carefully unclip and pull out on the
dashboard panel just enough to expose
the speaker pod. Remove (3) Phillips
screws securing the pod, then unclip,
unplug and remove. (Figure V)
Continue to Kit Assembly
