Line Tracer
22
5. Meintenance
5.1. Battery Replacement for Transmitter T10K
Disconnect all test leads before opening the battery cover.
Unscrew all four screws at the bottom of case.
Remove the cover.
Replace all four battery cells. Pay attention to correct battery polarity.
Fix the cover with all four screws to original position.
The transmitter is energized with four alkaline AA size 1.5 V battery cells.
5.2. Battery Replacement for Receiver R10K
Unscrew two screws on the bottom of casing.
Remove the cover.
Replace the battery. Pay attention to correct battery polarity.
Fix the cover back to the original position.
Receiver is energized with one 9 V battery (IEC 6LR61).
5.3. Cleaning
Use soft patch moistened by water or alcohol, and leave the instrument to dry totally
after the cleaning.
Do not use liquids based on petrol!
Do not spill cleaning liquid over the instrument!
5.4. Service
In case of any instrument malfunction or damage, noticed on the instrument or its
accessories, a competent service department must service the instrument. Contact your
dealer for detailed information.
