17/12/09 Aura User Manual Issue 5
11
Aura operation
Unlocking the cabinet door
The following procedure assumes the Aura has Application file (page38)
Configuration file (page39), tariff file (page40) and if required a key list file
(page41) loaded. The Dallas key, used to open the upper case and the vault
doors, must be compiled in the key list file. The cabinet door is opened using the
Dallas key and a Kaba 20 key. Place the upper case Dallas key onto the receptor
mounted in the right side of the coin return cup. The Dallas key is checked for
authenticity with the key list and if it matches, the shutter covering the Kaba 20
lock in the upper case will open.
Insert the key and turn clockwise, releasing the locking pins. The door will move
forward allowing it to be opened fully.
Kaba 20 lock shutter closed
Kaba 20 lock shutter open with key
Door open
Dallas key
