17/12/09 Aura User Manual Issue 5
14
Isolating the power
S1 located on the PCB,
switches the Aura on and off
electronically.
The single switch located to the
rear of the cabinet of a solar
powered Aura. This isolates the
12v supply to the PBC.
Isolating power in a solar machine
A mains powered machine PSU
is fitted to the rear of the cabinet.
This unit has two rocker
switches:
Caution this component may be
Hot.
The black switch on the left of
the unit isolates the 12v supply
to the PCB.
The Red neon switch isolates
the 230v main supply.
Isolating power in a mains machine
