Chapter II
Portable digital multimeters 31
5.3. Accessories
5.3.1. Supplied with the multimeter
1 set of test leads with safety probes AG0475AZ
1 6LF22 9 V battery P01100620
1 user’s manual
1 verification certificate
1 protective elastomer case AE0237
1 carrying case 280 x 210 x 80 with foam
(with some models only)
5.3.2. Optional
Measuring accessories
Set of accessories for electronics P01101894
Set of accessories for electricity P01101895
Probes
CA801, TC K temperature adapter, 1 channel, 1 mV/°C P 01652401Z
CA802, TC K temperature adapter, 2 channels, 1 mV/°C
with differential measurement P01652411Z
CA1871, IR temperature measuring probe without contact,
1 mV/°C, -30°C to +550°C P01651610Z
CA1711, laser optical tachometer probe, 1 impuls/revolution P01102082
AC Current clamps
MN12 clamp, 0.5 to 240 A
AC, 1 AAC/10 mVAC,
20 mm max cable Ø, 4 mm socket connection P01120405
MN89 clamp, 0.5 to 240 AAC, 1 AAC/100 mVAC,
20 mm max cable Ø, 4 mm socket connection P01120415
C100 clamp, 0.1 to 1200 AAC (not suitable for MX 23)
1 AAC/1 mAAC, 52 mm max cable Ø, 4 mm socket connection P01120301
Flexible AmpFlex 45 cm sensor, 0.5 to 200 AAC or 2000 AAC,
1 AAC/10 mVAC ou 1 mVAC, 4 mm socket connection P01120504
AC/DC Current clamps
K2 clamp, 0.1 to 450 mADC or 0.1 to 450 mAAC peak,
1 mA/10 mV, 3.9 mm max cable Ø, 4 mm pin connection P01120074
E6N clamp, 5 mA to 2 ADC ou 5 mA to 1.5 AAC or 20 mA to 80 AAC/DC,
1 A/1 V ou 10 mV, 11.8 mm max cable Ø, 4 mm pin connection P01120040A
PAC21 clamp, 0.4 to 1400 ADC or 0.2 to 1000 AAC, 1 A/1 mV or 10 mV,
39 mm max cable Ø, 4 mm pin connection P01120069
Shunts
30 A
DC / 300 mV, ± 0.5 % HA030-1
50 ADC / 50 mV, ± 0.5 % HA050-1
Transport
180 x 265 x 55 multimeter & accessories carrying bag AE0190
Mulimeter soft carrying bag HX0018
280 x 210 x 80 METRIX carrying case, with foam HX0009
