To clean the ue pipe of your Metro, proceed as follows:-
• Open the Metro’s door fully, reach inside with the palm
of your hand face-up and extended, lift the top bafe
approximately 20mm, then lift it forward out through the
door opening, placing it on a sheet of newspaper you
have placed on the front of the oor protector.
Note: Some appliances have a two piece top baffle.
• Close the door and slide the air control to the left.
• Once on the roof, remove the cowl from the top of ue
system and sweep the ue pipe using a 150mm-diameter
ue pipe brush as detailed in the instructions provided with
the uebrush.
• Once the ue pipe is clear, clean and ret the cowl.
Remove the excess soot which has fallen into the rebox,
leaving a layer of ash 10mm deep on the base of the
rebox, then ret the top bafe.
Note: The baffle must be fitted so its rear is touching the back of the
firebox; if uncertain refer to page 5 in the installation section at the front
of this manual, which shows illustrations of the baffle location.
Cleaning and maintenance for your Metro wood re
Parts guide for your Metro – Bafe, promet and wetback
Listed below are the parts and product codes for your Metro
wood re. The promet/bafe should be regularly checked and
must always be in place during the operation of your re.
Note: Cracks in the promet are not uncommon and have no adverse
effect on the operation of your Metro. These cracks are the result of
intense heat coupled with expansion and contraction and is normal
wear & tear.
Your Metro wood re must be regularly maintained and we
recommended it is also serviced annually. If a wood re is
not regularly maintained and serviced, the life span will be
reduced. If your Metro wood re has been neglected, by not
being regularly maintained and serviced, with authorised Metro
parts replaced as required, your warranty may be declined.
Clean air model
Type of promet required / Type of steel bafe(s) required Water heating options
• LTD Insert
LTD Small 500-1700 LTD Insert Front 500-2850 ECO/LTD Insert Rear (steel only)
500-2300
LTD 3kW Wetback 450-0100 or
LTD 4kW Wetback 450-0150
420mm
110mm
420mm
250mm
420mm
125mm
