This Metro wood re has been tested to and complies with
AS/NZS2918:2001 incorporating Appendix “E” when installed
in accordance with this manual. Please ensure you are fully
conversant with this relevant standard and the contents of this
manual. Correct installation is critical to the safe operation and
performance of this wood re.
Please take particular note of the following:
• It is recommended that Metro’s be installed with a Metro
ECO ue system which has been developed to enhance the
performance of Metro wood res. Any alternative ue system
must have a minimum ue pipe length of 4.1 metres of 150mm
diameter ue pipe & have been tested to AS/NZS2918:2001.
• The 150mm active ue pipe must be fully encased from the
top of the chimney to the underside of the ashing cone at
the top of the ue system (i.e. there must not be any 150mm
ue pipe exposed).
• All ue pipe joints must be sealed and riveted. The bottom of
the ue pipe in particular MUST be fully sealed into the ue
outlet of the Metro wood re.
• Ensure a breglass seal is placed between the outer cabinet
and the masonry to prevent air from within the room being
drawn into the chimney cavity.
• In New Zealand, the Metro Insert must be bolted securely to
the base of the chimney cavity to comply with the seismic
restraint provisions of AS/NZS2918.2001.
• The Metro fascia is coated in vitreous enamel. Please take
care during assembly and when lifting or tting the fascia
that you do not damage this coating. Do not lift the Metro
fascia with your ngers under the louvre’s.
• WE HIGHLY RECOMMEND YOU READ THIS ENTIRE
MANUAL AS INCORRECT OPERATION, MISUSE AND/OR
LACK OF MAINTENANCE WILL VOID THE WARRANTY
• The appliance and ue-system shall be installed in
accordance with AS/NZS2918 and the appropriate
requirements of the relevant building code or codes
• Any modication of the appliance that has not
been approved in writing by the testing authority is
considered to be in breach of the approval granted for
compliance with AS/NZS4013 and will void the warranty
•
The appliance must be installed correctly. We recommend
a competent and suitably qualied NZHHA installer
WARNING! Important Information
• Mixing of appliance or ue-system components
from different sources or modifying the dimensional
specication or components may result in hazardous
conditions. Where such action is considered, the
manufacturer should be consulted in the rst instance
• Do not install a Metro re if there is any sign of visible
damage to the product
• This appliance must be regularly maintained.
• Use authorised Metro replacement parts only. The use of
unauthorised parts may void the warranty
• This manual must be left with the home owner
CAUTION! Important Information
Familiarise yourself with the Metro Insert
All Metro replace insert wood res are packed into two
separate cartons: -
• The replace insert rebox is supplied in a heavy duty
palletised carton.
• The fascia and door are packaged inside a smaller
separate carton. This carton is clearly labelled to show
the colour and coating nish of the fascia and door.
Metro LTD fascia’s are coated in matt black vitreous
enamel.
Having removed the packaging and located this manual,
familiarise yourself with Diagram 1.
Fascia
Diagram 1
Fireplace
Insert
Firebox
Fibretex Blanket
Cabinet Top
Speed
Clip (X4)
Insert
Cabinet
Air
Control
Knob
Handle
Door
Fixing Points
For Seismic
Restraint
Spacer Washer
Hinge Pin
Spindle
A
B
