Basic specification
The transmitter communicates with the receiver using 2.4GHz ISM band.
The receiver receives touching signal, battery alarm signal and communication alarm signal from
the transmitter and outputs the decoded signals to CNC controller through the cable.
This system gains FCC, CE, TELEC (JAPAN), SRCC (CHINA) and RoHS, WEEE certification.
2-1
Common specification
2-2
Transmitter specification
1 LED（Red：signal output of transmitter）
1/2AA thionyl chloride battery
Once battery is installed to the battery holder, the current consumption starts.
For long-term storage, it is recommendable to remove the battery from the battery holder.
Weight（excluding a shank）
With battery：290g / Without battery：280g
Battery life（calculation）
5% use（72min/day) ： 87 days
Continuous use
： 180 hours
2-3
Receiver specification
Receiver performs communication exclusively with the transmitter using its ID number
after coupling operation.
4 LEDs (Blue：Power, Orange : Battery alarm, Green：Communication status, Blue :
Skip signal output of transmitter)
φ7.2/14 cores oil resistant cable with watreproof connector
Input : power source (DC 24V), M code（power ON/OFF signal）
Output : Skip signal (Probe status 2a), Probe status1, Battery alarm, Probe status 2b）
Min.1ms
(From transmitter turns ON until receiver skip signal activates. However, this depends on communicatin status)
Max. 0dBm (without antenna)
Max. -82dBm (without antenna)
