Metso Orion Series User Manual

Slurry Pump
WH07MM1AAA0en_05b.doc JAN 04-W08
Description
1/1
2.4 Materials and maximum working pressures
Metso Minerals Slurry Pumps are constructed from materials selected to give excellent
wear characteristics over the full range of pumping duties. This section lists the materials
of construction and working pressures for STANDARD duty applications.
Other materials are also used for specialist applications or as specified by the customer
– see section 1.3 .
MATERIALS OF CONSTRUCTION
Item Material Type Material Code Material Standard
Case White Cast Iron JN3049 EN 12513
Impeller White Cast Iron JN3049 EN 12513
Back Liner White Cast Iron JN3049 EN 12513
Bearing Frame Cast Iron JS1030 EN 1563
Expeller White Cast Iron JN3049 EN 12513
Expeller Ring White Cast Iron JN3049 EN 12513
Expeller Ring (option) Cast Iron JS1030 PU Lined EN 1563
Stuffing Box Cast Iron JS1030 EN 1563
Shaft Sleeve White Cast Iron JN3049 EN 12513
Shaft Sleeve (option) Stainless Steel 1.4401 EN 10088
Shaft Sleeve (option) Stainless Steel 1.4021 EN 10088
Shaft Sleeve (option) Stainless Steel 1.4462 EN 10088
Shaft Steel 1.1191 EN 10083
Seals Nitrile Rubber NBR -
PUMP WORKING PRESSURES
SIZE Bar kPa
MM100 to MM400 15.0 1500
