Page 27
BEATER AND APRON DRIVE PARTS
KEY PART NO. QTY
125
QTY.
160
QTY
225
DESCRIPTION
1 E01840-1.5 1 1 1 Bracket, Right Rear
2 REF 1 1 1 Box, Gear - (see separate listing)
3 E02127 1 1 1 Clutch Cable Angle Bracket with Two 1/2” Nuts
4 E01842 1 1 1 Coupling, Drive
5 E01843 1 1 1 Chain, Apron Drive #60-60 Pitches
6 E01844 1 1 1 Bracket
7 E01845-04 1 1 1 Shield, Gear Case Side
8 E01846-04 1 1 1 Shield, Main Gear Box
9 E01848 1 1 1 Plastic Spool Chain Tension, Adjusting Only
10 E01796 2 2 2 Tightener Bracket
11 E01850-04 1 1 1 Shield, Top
12 E01851 1 1 1 Chain, Beater Drive - #60-52 Pitches
13 E01852 1 1 1 Sprocket, Apron Drive - 60B16 - 1-1/4", 5/16" Keyway
14 E01853 1 1 1 Sprocket, Beater Drive - 60B16 - 1-3/8", 3/8" Keyway
15 E01972-1.5 1 1 1 Sprocket, Beater Drive - 60B22 - 1-1/2", 3/8" Keyway 2011 Rev
16 E01855 1 1 1 Sprocket, Apron Driven - 60A40 - 1-1/2" (Standard)
E01856 1 1 1 Sprocket, Apron Driven - 60A36 - 1-1/2" (Speed Up)
E01857 1 1 1 Sprocket, Apron Driven - 60A48 - 1-1/2" (Slow Down)
17 E01858 1 1 1 Hub, Shear for Apron Drive
18 E01860 2 2 2 Bolt, Shear GR2 - 7/16x1-1/2"
19 E01862 1 1 1 Spring, Tension Beater
20 E01863 2 2 2 Spacer
21 E01864 1 1 1 Spacer, Split 3/8” wide
22 E01865 1 1 1 Spring, Tension Apron
23 E00016 1 1 1 Lock Assy, Complete
24 E01273 1 1 1 Hinge
25 E01274 1 1 1 Cable Door Stop
26 E00311-00 1 1 1 Tension Adjuster, 1/2” Bore, Rubber
27 E01932 1 1 1 Cable Thimble
