APPENDIX A: MEYER SOUND WEATHER PROTECTION
35
IP RATINGS
IP stands for "Ingress Protection." The current format for expressing an IP rating is a 2-digit code. The first digit of an IP
rating represents protection from solid objects. The second digit of an IP rating represents protection from water or
moisture. Table 6 provides a chart of IP ratings and the corresponding definitions of the rating.
NOTE: IP ratings only apply to the "ENCLOSURE." A loudspeaker is considered an enclosure and as such we
can apply an IP rating to it. Rigging hardware is not an enclosure and therefore IP ratings do not apply. Also,
cable and cable-mount connectors used to connect to the loudspeaker are NOT part of the enclosure and therefore
not part of the IP rating. Only the chassis-mounted part of the connector is considered part of the enclosure.
Table 6: IP Ratings Definition Chart
First Digit
(Protection against solid
objects)
DefinitionSecond Digit
(Protection against
liquids)
Definition
XCharacteristic numeral is
not required to be specified.
XCharacteristic numeral is
not required to be specified.
0No protection0No protection
1Protected against solid
objects over 50mm.
1Protected against vertically
falling drops of water.
2Protected against solid
objects over 12 mm.
2Protected against direct
sprays up to 15° from the
vertical.
3Protected against solid
objects over 2.5mm.
3Protected against direct
sprays up to 60° from the
vertical
4Protected against solid
objects over 1 mm.
4Protected against direct
sprays from all directions.
Limited ingress permitted
5Protected against dust.
Limited ingress permitted.
5Protected against
low-pressure jets of water
from all directions. Limited
ingress permitted.
6Totally protected against
dust.
6Protected against strong
jets of water from all
directions. Limited ingress
permitted.
7Protected against the effect
of temporary immersion
between 15cm and 1m.
8Protected against the effect
of long-term submersion of
1m or more.
