RF lter Common mode: 425 kHz; Differential mode: 142 kHz
TIM lter <80 kHz, integral to signal processing
Nominal input sensitivity 0 dBV (1 V rms, 1.4 V pk) continuous is typically the onset of limiting for pink noise and music.
Input level Audio source must be capable of producing a minimum of +20 dBV (10 V rms, 14 V pk)
into 600 ohms in order to produce maximum peak SPL over the operating bandwidth of the
loudspeaker.
AMPLIFIER
Amplier type Two-channel complementary MOSFET output stages (class AB/bridged)
Output power 700 W total
Note: Wattage rating is based on the maximum unclipped burst sine-wave rms voltage the
amplier will produce into the nominal load impedance — low channel 30 V rms (42 V pk);
high channel 32 V rms (45 V pk)
THD, IM TIM < .02%
Load capacity 2 Ω low channel, 8 Ω high channel
Cooling Convection cooling. 24 V DC output for optional external fan.
AC POWER
AC power connector PowerCon or VEAM
Voltage selection Automatic
Safety agency rated
operating voltage
100 V AC - 240 V AC; 50/60 Hz
Turn on/turn off points Continuous 90 V AC - 265 V AC; 50/60 Hz
Note: No automatic turn-off voltages. Voltages above 265 V AC are fuse protected but
may cause permanent damage to the power supply. Voltages below 90 V AC may result in
intermittent operation.
Current Draw
Idle current 0.35 A rms (115 V AC); 0.35 A rms (230 V AC); 0.35 A rms (100 V AC)
Max. long-term continuous
current (>10 sec)
3.1 A rms (115 V AC); 1.6 A rms (230 V AC); 3.6 A rms (100 V AC)
Burst Current (<1 sec) 3.2 A rms (115 V AC); 1.6 A rms (230 V AC); 3.7 A rms (100 V AC)
Ultimate short-term peak
current draw
5.8 A pk (115 V AC); 2.9 A pk (230 V AC); 6.7 A pk (100 V AC)
Inrush current 9 A pk (115 V AC); 9 A pk (230 V AC); 8 A pk (100 V AC)
RMS NETWORK
Equipped for two conductor twisted-pair network, reporting all operating parameters of
ampliers to system operator’s host computer.
PHYSICAL
Enclosure Multi-ply hardwood
Finish Black textured
Protective grille Powder-coated hex stamped steel
Rigging Patented QuickFly MRF-2D rigging frame with CamLinks and quick release pins
Dimensions 39.00" w x 12.12" h x 17.47" d (991 mm x 308 mm x 444 mm)
39.00
[991 mm]
37.00
[940 mm]
9.99
[254 mm]
12.12
[308 mm]
17.47
[444 mm]
6.06
[154 mm]
19.56
[497 mm]
8.74
[222 mm]
39.00
[991 mm]
37.00
[940 mm]
9.99
[254 mm]
12.12
[308 mm]
17.47
[444 mm]
6.06
[154 mm]
19.56
[497 mm]
8.74
[222 mm]
Weight 116 lbs (52.62 kg); Shipping 130 lbs (58.97 kg)
