19
APPENDIX B
27.07
[688mm]
16.11
[409mm]
8.80
[223mm]
40¡
13.70
[348mm]
23.00
[584mm]
40¡
PHYSICAL
Enclosure
Premium bir
ch plywood
Finish
Black textured
Protective grille
Powder
-coated, hex-stamped steel, black mesh
Dimensions
27.07" w x 16.11" h x 23.00" d (688 mm x 409 mm x 584 mm)
W
eight
108 lbs (49 kg)
24
26
Table of Contents
Default Chapter
1
Operating Instructions
1
Important Safety Instructions
3
Safety Summary
4
Table of Contents
5
Introduction
7
CHAPTER 1: Introducing the Mjf-212A High-Power Stage Monitor
9
Advanced MJF-212A Driver Technology
9
Integrated Amplifier and Processing
10
Total System Approach
10
CHAPTER 2: Power Requirements
11
AC Power Distribution
11
Looping and Cabling
11
Power Connector Wiring Conventions
12
Voltage Requirements
12
Current Requirements
13
Electrical Safety Issues
14
CHAPTER 3: Amplification and Audio
15
Audio Input
15
Amplification and Protection Circuitry
15
MJF-212A Interconnections
16
Cabling
16
The Limiting System
16
Low-Frequency Limiter
16
High-Frequency Limiter
16
Cooling System
17
CHAPTER 4: Rms Remote Monitoring System
19
Understanding the RMS Module
19
Service LED (Red)
19
Service Button
20
Wink LED (Green)
20
Reset Button
20
Activity LED (Green)
20
User Interface
20
Appendix A: Optional Veam Multipin Connector
21
Appendix B: Mjf-212A Specifications and Dimensional Drawings
23
