MFJ-259 Instruction Manual HF/VHF SWR Analyzer
17
Designator Description Part Number
J5 Jack, 2.1 mm, DC Coaxial Jack 601-6021
J6 Connector, BNC, Chassis Mt. Female, UG-652/U 610-1016
JMP1-JMP3 Wire, Jumper, 1/4"-2" 870-5000
L1
Inductor, Var, 66
µ
H
402-3412
L2
Inductor, Xformer, 1 7.8
µ
H
402-3406
L3
Inductor, Xformer, 1.8
µ
H
402-3402
L4
Inductor, .211
µ
H
402-2728
L5 PCB Coil, Air Wound, 4 Turn 10-01014
L6 PCB Coil, Air Wound, .5 Turn 10-01011
L7 Pick-up Coil, #61 Pre-wound 10-01003
M1 Meter, 100 uA, SWR Meter 400-0035
M2 Meter, Resistance 400-0045
MOD1 Counter Module, LCD 50-247-3
P2 Connector, IDC, Socket, 3 Positions 612-2003
PCB PCB, 2-side, MFJ-259 862-0249
Q1,Q2,Q4 Transistor, FET, To-92, Siliconix, J310 305-6310
Q3 Transistor, FET, Switching, VN10KM 305-6005
Q5 Transistor, HF Wide Band, To-39, NPN, 2N5109 305-0017
R1 Resistor, 1/4 Watt, 5%, Film, 18 Ohm 100-1180
R10 Resistor, 1/4 Watt, 5%, Film, 39k Ohm 100-4390
R15,R24,R29,R30 Resistor, 1/4 Watt, 5%, Film, 10.0k Ohm 100-4100
R17,R32 Resistor, Trimpot, Sub. Horz., 10 K 133-4100
R18 Resistor, Trimpot, Sub. Horz., 100 K 133-5100
R2,R21,R22 Resistor, 1/4 Watt, 5%, Film, 1M Ohm 100-6100
R26,R27,R28 Resistor, 1/8 Watt, 1%,49.9 Ohm 102-1499
R3,R8 Resistor, 1/4 Watt, 5%, Film, 100 Ohm 100-2100
R33 Resistor, 1/4 Watt, 5%, Film, 620 Ohm 100-2620
R4,R7 Resistor, 1/4 Watt, 5%, Film, 10 Ohm 100-1100
R5,R6 Resistor, 1/4 Watt, 5%, Film, 1.0k Ohm 100-3100
R9 Resistor, 1/4 Watt, 5%, Film, 100k Ohm 100-5100
SW1 Switch, Rotary, 2p6p 500-1565
SW3,SW4 Switch, Push Button, spst 504-1003
SW2 Switch, Push-Button, 2p2p 504-0022
