MFJ – 57B Instruction Manual PVC Cross Loop Antenna Kit
2
Figure 1: PVC Cross Mount Loop
Assembly
Notched PVC
Cross Arms
(2)
PVC
Cross Connector
(3)
Un-notched
PVC
Cross Base
(4)
Loop
Tuner
(6)
Flexible
Loop
(1)
Cap
(5)
