MFZ Ovitor STA 1 - Document Information and Safety; Original Operating Instructions; Key to Symbols

2 – Sectional door operator STA 1 / Rev. D 0.4 Sectional door operator STA 1 / Rev. D 0.4 – 3
2 – Sectional door operator STA 1 / Rev. D 0.4
1. Contents
1. Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2. Information in this document . . . . . . . . . . . . .2
3. General safety instructions . . . . . . . . . . . . . . .3
4. Overview of products. . . . . . . . . . . . . . . . . . . .4
5. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . .5
5.1 Preparation.........................5
5.2 Push-on assembly....................5
5.3 Installation of the emergency hand chain
(only for operators with emergency hand
chain).............................6
6. Initial Operation. . . . . . . . . . . . . . . . . . . . . . . .7
6.1 Preparation.........................7
6.2 Connection.........................7
6.3 Manual settings ....................10
6.4 Digital settings –
Limit switch and safety circuit for drive ...11
6.5 Check the system ...................12
7. Emergency operation. . . . . . . . . . . . . . . . . . .12
8. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . .14
9. Technical data . . . . . . . . . . . . . . . . . . . . . . . .15
10. Manufacturer‘s Declaration . . . . . . . . . . . . . .22
Original operating instructions
− Copyright.
− No part of these instructions may be reproduced without
our prior approval.
− Subject to alterations in the interest of technical progress.
− All dimensions given in mm.
− The diagrams in this manual are not to scale.
Key to symbols
DANGER!
Indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
WARNING!
Indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
CAUTION!
Indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
ATTENTION!
Indicates an imminent danger of damage or destruction.
CHECK
Indicates a check to be performed.
REFERENCE
Reference to separate documents which must be complied
with.
☞ Action request
− List, itemisation
➔ Reference to other sections of this document
2. Information in this document
