Control CS 320 / Rev.B 1.01 – 41
Function Description
Adjustment
options
Factory setting
SELF LOCK Selection between pulse operation and manual operation (dead man) with or without
evaluation of closing edge safety device (SKS) and light barrier system (LB).
MOD1: Pulse operation for OPEN + CLOSE with SKS and LB
With defective safety equipment, switch over to manual operation.
MOD2: Manual operation for OPEN + CLOSE with SKS and LB
MOD3: Manual operation for CLOSE, pulse operation for OPEN, with SKS and LB
MOD4: Manual operation for OPEN, pulse operation for CLOSE, with SKS and LB
MOD5: Manual operation for OPEN + CLOSE without SKS and LB
MOD6: Manual operation for CLOSE, pulse operation for OPEN, without SKS
andLB
MOD7: Manual operation for OPEN + CLOSE with SKS and LB
STOP upon reaching the intermediate position CLOSE.
By pressing the button again, continued travel to end position CLOSED
is possible.
MOD8: Pulse operation for OPEN + CLOSE with SKS and LB
With defective safety equipment, switch over to manual operation only
via circuit board button
MOD9: Manual operation for OPEN + CLOSE with SKS and LB
With defective safety equipment, operation only via circuit board button.
MOD1 – MOD9 MOD1
POWER Automatic power monitoring
(Monitoring of the rotational speed)
Faultmessageintheeventofthedoorbeingdifculttomoveorblocked.
Adjustment of the sensitivity for OPEN direction.
A value for the force (rotational speed) will be displayed during opening.
With the power monitoring active, the value must be set to a lower value than the
lowest value shown during the door travel. The greater the difference to the lowest
displayed value, the less sensitive the reaction of the power monitoring.
The power monitoring is only activated if the numeric value is set.
OFF
1 – 999
10
RESET
MSBUS
All assigned MSBUS addresses are reset.
After a controller restart, re-addressing of all connected MSBUS devices takes place.
➔ For detailed information refer to the manual for the MSBUS device.
ON
OFF
OFF
RESTART With activation of the function, the controller is restarted. ON
OFF
OFF
FACTORY SET. Selection of the parameter set that should be reset with a RESET.
MOD5: MFZ S ➜ Drives in dead man operation
MOD6: MFZ FU ➜ Drive series MDF-U (integrated UPS)
MOD7: MFZ S ➜ Drive series STAW with increased switch-on duration
MOD8: MFZ FU ➜ Drive series MTZ 05 (230V)
MOD9: MFZ FU ➜ Drive series STA
MOD14: MFZ FU ➜ Drive series MTZ 05 (400V)
MOD28: MFZ S ➜ MFZ mains operation with brake actuation.
MOD31: MFZ S ➜ Dead-mans function, not resettable
MOD32: MFZ DUO ➜ DUO-system, 2 drives
MOD98: MFZ S ➜ Standard with brake monitoring (relay 4 / MOD14)
MOD99: MFZ S ➜ Standard
MOD10–MOD13/MOD15–MOD97:Customer-specicparametersets
MOD5 – MOD99 MOD99
RESET Reset control parameters to the pre-selected factory settings.
MOD1: Part reset 1 (everything apart from frequency converter settings)
MOD2: Part reset 2 (everything apart from limit positions / known limit position
system)
MOD3: Complete reset (everything is reset to factory settings)
OFF,
MOD1 – MOD3
OFF
