42 – Control CS 320 / Rev.B 1.01
Functional overviews
Function Description
Adjustment
options
Factory setting
PIN no. 2 Input and selection of a PIN code for programming a service interval.
After inputting the PIN code, the second programming level opens.
Afterwards, a service interval can be entered via the SERVICE parameter. Input level 2
disappears again after the voltage is switched off, or automatically after 10 minutes.
AchangetothePINcodecanonlytakeplaceinthesecondprogramminglevel.
0 – 9999 1111
SERVICE OFF: Service display not active
Setting a service interval. After the set load cycles are complete, a service message is
issued (LED / LCD). If a relay output is programmed with MOD31, the respective relay
(continuous signal) switches.
Only appears after activation of input level 2 via parameter PIN no. 2.
OFF
0 – 99950
OFF
INVERTER Activates or deactivates a connected frequency converter. By connecting a frequency
convertertointerfaceX18thecontrollerbecomesanCS320FU.
➔ FordetailedinformationrefertothemanualfortheCS320FU.
MOD1: Operation without frequency converter
MOD2: Operation with frequency converter
MOD3: Operation with frequency converter (effective ramp times)
MOD1 – MOD3 MOD1
EXPERT
MENU
Activation and deactivation of the expert setting.
With the factory setting OFF, only a limited selection of parameters appears in the
INPUT. If this parameter is set to ON, it is possible to call up and set all input menu
parameters.
OFF: Limited number of parameter settings:
– Menu language
– INT POS UP
– OPEN TIME
– FOREWARNING TIME
– FAST CLOSE
– REVERSE OFF
– INPUT 1
– SELF LOCK
– EXPERT MENU
ON: Access to all parameters as listed in chapter 10.2.
ON – OFF OFF
