The configuration parameters available are in sequence:

code 11 Max settable temperature for pre-heating. Configure the adjustment limit of the hP

parameter. The absolute maximum that can be set is 100°.

code 12 Max settable temperature for heating. Configure the adjustment limit of the parameter

ht. When the adjustment with potentiometer is used, this will adjust between a minimum set

with the parameter ht and this maximum value. The absolute maximum settable is 500°.

code 13 Operating mode. See operating modes section of the manual

0 = adjustment only activates when inputs activate at the relevant temperatures set

1 = adjustment activates at the input pre-heating temperature for heating.

2 = timed heating cycle aborts if input removed.

3 = timed heating cycle after impulse on heating input.

code 14 Timers unit of measurement selection. It allows to operate with times up to 99.9 sec.

CEn (timing in hundredths of a second)

dEC (timing in tenths of a second)

code 15 Select temperature unit of measurement.

C (degrees Centigrade)

F (degrees Fahrenheit)

code 16 Analogue input voltage selection. Allows you to adjust the temperature with a

potentiometer connected to the device or with an external 0-10V voltage connected instead of

the potentiometer.

POt input 0-5V with potentiometer

U01 input 0-10V

code 17 Alloy used in heater. Indicates to the TR-evo which material the heating element is made

of, to allow the correct temperature indication.

1 = Nichrome40

2 = AISI 316

3 = Alloy20

4 = MS500

5-9 = Others

code 18 Increment at minimum firing TRIAC This parameter allows you to change how the

heating element is powered to improve performance in certain specific cases. The parameter

can take values between 0 and 20. Normally it should be left at 0.

code 19 Loop gain setting. It allows to adapt the temperature control according to the specific

power used in particular situations. The parameter can assume values between 0 (very low

gain, when specific power is very high) and 30 (high gain to try to compensate very low

specific power). The default value is 5 valid for most configurations.

code 20 Serial bus mode. Select communication format depending on the other connected

devices.

72 = (7 + 2stop)
