06 Names of individual components and their functions (T-box)
Names Description
①
Power source / data cable Power source/data cable connected to the main unit
②
Vehicle power cable A power cable connected to the car’s fuse box
③
SD card insertion part The part where the SD card for video storage is inserted
④
EMGCY A socket that connects the external emergency button
⑤
TV OUT A socket that connects the display device
⑥
CAM A socket that connects the third camera (Optional)
⑦
I/O1, I/O2 Wires used to input external sync signals
