JNR & WNK Assembly Instructions
CARTON CONTENTS
MODEL JNR GRILL
Parts
Quantity
Top Casting (Grill Lid) 1
Bottom Casting (Grill Head) 1
Sta-Kool Handle 1
Handle End Caps 2
Warming Rack 1
Bottom Grate 1
Porcelain Cooking Grids 1 (SearMagic 2)
Control Panel Brackets 2
Heat Shield 1
Grease Cup Holder 1
Control Panel Assembly 1
Valve Control Knobs 2
Ignitor Knob 1
Side Shelf 1
Side Shelf Bracket 1
Venturi Tube Cleaning Brush 1
Bag of Briquettes (53 pieces) 1
Meat Probe 1
Forked Grid Cleaning Tool 1 (SearMagic Only)
Hardware Quantity
Connecting Wire for Ignitor 1
¼-20 x 1½" Rd. Hd. Sltd. Bolt 4
¼-20 x ½" Rd. Hd. Sltd. Bolt 2
¼-20 x ¾" Hex head Bolts 3
¼-20 x 1" Hex head Bolts 4
¼-20 x 1½" Hex Head Bolt 2
¼-20 KEP Nut 11
Keeper Washer 2
Graphite Washer 2
Flat Washer for Ignitor 1
1/8-27 Jam Connecting Nut 1
Lid Pivot Pin 2
Hitch Pin for Lid 2
MODEL WNK GRILL
Parts Quantity
Top Casting (Grill Lid) 1
Bottom Casting (Grill Head) 1
Sta-Kool Handle 1
Handle End Caps 2
Warming Rack 1
Bottom Grate 1
Stainless Steel Cooking Grids 2 (SearMagic 3)
Control Panel Brackets 2
Heat Shield 1
Grease Cup Holder 1
Control Panel Assembly 1
Valve Control Knobs 2
Ignitor Knob 2
Side Shelf 2
Side Shelf Bracket 2
Venturi Tube Cleaning Brush 1
Bag of Briquettes (63 Pieces) 1
Meat Probe 1
Forked Grid Cleaning Tool 1 (SearMagic Only)
Hardware Kit Quantity
Connecting Wire for Ignitor 1
¼-20 x 1½" Rd. Hd. Sltd. Bolt 6
¼-20 x ½" Rd. Hd. Sltd. Bolt 2
¼-20 x ¾" Hex head Bolts 3
¼-20 x 1" Hex head Bolts 8
¼-20 x 1½" Hex Head Bolt 2
¼-20 KEP Nut 13
Keeper Washer 2
Graphite Washer 2
Flat Washer for Ignitor 1
1/8-27 Jam Connecting Nut 1
Lid Pivot Pin 2
Hitch Pin for Lid 2
Please check to be sure that all parts are included before proceeding with assembly. Contact your local dealer
if any parts are missing.
Note: The grill is partially assembled. The Burner, Spider Guards, Venturis, Ignitor Collector
Box are installed. Also, for LP units the Gaslow Regulator and Hose are installed.
