31
Parts Information
TJK and WNK Stainless Steel Optimum
Console Mount (Nat. & LP)
Item Qty. Description
84 1 Stainless Steel Front Panel
85 1 Cast Aluminum Base
86 1 Stainless Steel Column
87 1 Heat Shield
82 1 Stainless Grease Cup
87 4 ¼ - 20x1¼ S.S. Hex Head Bolt
88 12 ¼ - 20 S.S. Kep Nuts
89 10 ¼ - S.S. Flat Washers
90 1 6 “ Wheels (Cart Only)
91 1 Axle (Cart Only)
92 1 Tank Lock Bar
93 4 Rectangular Washers
94 8 ¼ - 20 x ¾” S.S. Hex Head Bolt
95 1 2-Piece Gasket
41 1 28” S.S. Tubing (Nat. Gas)
54 2 Hitch Pins
58 2 Plastic Hub Caps
62 1 12’ Hose (Nat. Gas)
63 1 Brass Quick-Disconnect (Nat. Gas)
67 1 Quick-Disconnect Dust Cap (Nat. Gas)
69 2 Dust Cap (Nat. Gas)
TJK and WNK Built-In Mount (Nat.)
(NMS)
Item Qty. Description
B1 1 Left Hand Door
B2 1 Right Hand Door
B3 1 Door Set Frame
B4 1 Door Handles
B5 1 Magnetic Catches
B6 1 Front Face Plate
B7 1 Right Side “L” Bracket
B8 1 Left Side “L” Bracket
B9 1 Rear Support Bracket
B10 1 Grease Tray
B12 12 ¼-20 x 3/4” Hex Head Bolt
B13 4 ¼ - 20x1¼ Hex Head Bolt
B14 4 ¼ - 20 Nut
B15 4 ¼ - 20 Flat Washer
B16 16 ¼ - 20 Lock Washer
B17 1 Heat Shield
SearMagic Warming Rack & Cooking Grids
Item Qty. Part # Description
78 3 GG-Grid-S SearMagic Grids (WNK & TJK)
79 2 HH-Grid-S SearMagic Grids (JNR)
80 1 GG-TS-S All Purpose Warming Rack
