TJK Assembly Instructions
MODEL TJK Grill
Parts Quantity
Top Lid Assembly 1
Bottom Casting (Grill Head) 1
Warming Rack 1
Bottom Grate 1
Stainless Steel Cooking Grids 2 (SearMagic 3)
Control Panel Brackets 2
Heat Shield 1
Grease Cup Holder 1
Control Panel Assembly 1
Valve Control Knobs 2
Ignitor Knob 2
Stainless Steel Side Shelf 2
Side Shelf Bracket 2
Condiment Holder 2
Venturi Tube Cleaning Brush 1
Bag of Briquettes (67 pieces) 1
Meat Probe 1
Forked Grid Cleaning Tool 1 (SearMagic Only)
Hardware Quantity
Connecting Wire for Ignitor 1
¼-20 x 1½” Rd. Hd. Sltd. Bolt 2
¼-20 x 1¼” Rd. Hd. Sltd. Bolt 4
10-24 x 1¼” Rd. Hd. Bolt 8
¼-20 x ¾” Hex Head Bolt 3
¼-20 x ½” Rd. Hd. Sltd. Bolt 2
10-24 KEP Nut 8
¼-20 KEP Nut 11
Keeper Washer 2
Flat Washer for Ignitor 1
1/8 – 27 Jam Connecting Nut 1
Lid Pivot Pin 2
Hitch Pin for Lid 2
CARTON CONTENTS
Please check to be sure that all parts are included before proceeding with assembly. Contact your local dealer
if any parts are missing.
Note: The grill is partially assembled. The Burner, Spider Guards, Venturis, Ignitor Collector
Box and the Stainless Steel Handle are installed. Also, for LP units the Gaslow Regulator and
Hose are installed.
