MHSC 36CDVXTRN - Fireplace Dimensions

5
CDVX Series Direct Vent Gas Fireplace
20012253
76”
(187 mm)
166”
(422 mm)
3656M” (921 mm)
Minimum Rough Opening Width
Minimum
Rough
Opening
Height
Minimum
Rough
Opening
Depth
*4856M” (1226 mm)
**416” (1051 mm)
*6856M” (1734 mm)
**586” (1483 mm)
1756”
(435 mm)
25” (635 mm)
22”
(559 mm)
1856O”
(470 mm)
2156”
(537 mm)
3556M” (895 mm)
35”
(889 mm)
346M”
(883 mm)
2(6”
(73 mm)
16”
(35 mm)
356M”
(83 mm)
Gas Line
Access
Gas Line
Access
Low Voltage
Electrical
Access
Electrical
Access
33” (838 mm)
C
L
Centerline of
7" Collar
856O”
(216 mm)
Low
Voltage
Access
16”
(35 mm)
76”
(187 mm)
856O”
(216 mm)
3256”
(816 mm)
14”
(356 mm)
10175
CDVXR specs
356M”
(83 mm)
*Must be adhered to
if using 7TCD45KT
Flex Vent Kit
**If using Rigid 45°
with Starter Pipe
*4856M” (1226 mm) **416” (1051 mm)
*3456
” (867 mm)
**29
56
” (740 mm)
Fireplace Dimensions - Rear Vent
Fig. 1 Fireplace specifications and framing dimensions.
*
*
*
*
