MHSC MLDV500 - Clearances

8
75D0004
MLDV Series Gas Fireplace
71” Minimum
Ceiling
12” Max.
Depth
14” Min.
From Opening
6” Min.
to Opening
FP1987
clearances


Figure 4 -
Side Wall and Ceiling Clearances
Figure 5 -
Mantel clearances.
6"
5"
3"
256O"
456O"
45°
356O"
1"
156O"
FP1949
mantel clearances
Fireplace
Opening
Wall
Combustible
Material Area
Side Wall
Combustible
Mantel








8” Max.
10”
Min.
756O”
Min.
156O”
Max.
256M” Max.
FP2916
Mantel Clearance
14”
Min.
12” Max.
3/4"
Marble
Combustible
Breastplate
Figure 5a -
Mantel Clearance with Eyebrow Canopy
 When eyebrow canopy is used, minimum clearance to
combustibles is Z\v" maximum out from replace front at 7Z\x"
minimum from opening. Figure 5a. When eyebrow is not used,
clearances to combustibles is 8" maximum out from replace
front at 10" minimum from opening or 1" maximum out from
replace front at 14" minimum from opening. Figure 5
Eyebrow
Canopy
