SB38 / SB44 Series Woodburning Fireplace
10
87D0057
Figure 7
FP2220
fireplace location
Corner
Full Protection
Flush
FP0

A
B
C
FP1531
hearth dimensions
9/04 djt
  
    
SB38/38HB 36” (914 mm) ” (559 mm) 0” (508 mm)
SB44/44HB 4” (1067 mm) 8” (711 mm) 0” (508 mm)

Figure 8
FP1531
