MHSC SB38 - Clearances

SB38 / SB44 Series Woodburning Fireplace
87D0057 7

Figure 3
476”
5356”
FP1875
SB4800 features
8/08
Chimney Cap
Roof Flashing
Flue Outlet Height to Floor
Storm
Collar
15 ft. = Min. Height (No offsets)
15 ft. = Min. Height ( 30° Elbows)
1 ft. = Min. Height (4 30° Elbows)
86 ft. = Max. Height (Chimney sup-
port every 5 ft.)
Chimney Sections
Maintain ” Minimum Air
Space Between Chim-
ney and Combustibles

Flexible Duct
Type FP-4-U
Combustion Air
Assembly
Nail to Framing Members
Galvanized Metal Strip
 Do Not Restrict
Side Air Inlet Vents with Sur-
round or Trim Materials
Floor Line
Top Spacer
Firestop
FP1875
