MHSC SB38 - Page 16

SB38 / SB44 Series Woodburning Fireplace
16
87D0057

FP531
surround flush with
finish wall
12/20/01 djt
12"
(305 mm)
Max.
18"
(457 mm)
min.
6”
(152 mm)
156O"
12"
(305 mm)
Max.
18"
(457 mm)
min.
156O"
6"
(152 mm)
Min.
3/4"
FP683
Figure 19 -
Mantel Clearance
Header
Must be sealed with non-
combustible material
Surround
Face
Finished Wall
Ledge Bracket
Finished Wall
Ledge Bracket
Combustible
Mantel and Trim


Fireplace Opening
Noncombustible
Material
Combustible
Mantel and Trim


Finished Wall
Header
Ledge Bracket
Noncombustible
Material
Surround
Face
Noncombustible Facing
Material
Fireplace Opening
 x 4 Stud
Finished Wall
Must be sealed with
noncombustible
material
