Micro Matic MMPP4305-PKG - User Manual

24 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

MMPP4301-EP

MMPP4301

MMPP4301-WC

MMPP4301-PKG

MMPP4301-PKG-WC

MMPP4302

MMPP4302-WC

MMPP4302-PKG

MMPP4302-PKG-WC

MMPP4303-PKG

MMPP4303-PKG-WC

MMPP4303-PKG-3

MMPP4305-PKG

MMPP4305-PKG-WC

MMPP4305-PKG-3

MMPP4305-PKG-WC3

MMPP4307-PKG

MMPP4307-PKG-WC

MMPP4307-PKG-3

MMPP4307-PKG-3-WC

MMPP4307-PKG-4

MMPP4307-PKG-4-WC

POWER PACK

SERVICE MANUAL

v3.0

Table of Contents

Questions and Answers

J
Jordan FordAug 9, 2025
Why is my Micro Matic MMPP4305-PKG Power Pack producing excessive foam?
- L
  leonardhernandezAug 9, 2025
  Excessive foam in your Micro Matic Power Pack can stem from several factors. The walk-in cooler might be too warm; adjust the cooler temperature to between 36° and 38° F using a quality thermometer. Also, check the applied pressure to the keg and adjust the regulator for a proper flow rate of two ounces per second. Inspect the physical equipment from the keg to the faucet. Warm product lines can also cause foaming.
K
Kristopher GibsonAug 20, 2025
What to do if the compressor on my Micro Matic Power Pack does not run but hums?
- R
  Rebecca AndersonAug 20, 2025
  If the compressor on your Micro Matic Power Pack doesn't start but hums, several issues could be at play. First, check for inadequate voltage by measuring it across the common and run terminals on the compressor; it must not drop below 90% of the rated voltage. A malfunctioning starting relay could also be the culprit; replace it, ensuring you use the correct relay to prevent compressor failure. Lastly, the compressor itself might be malfunctioning, requiring replacement.
K
Kristen WarnerAug 27, 2025
What to do if Micro Matic MMPP4305-PKG Power Pack compressor runs constantly and freezes up?
- J
  Jessica RivasAug 27, 2025
  If the compressor on your Micro Matic Power Pack runs continuously and doesn't cut off, leading to freeze-up, it could be due to a thermostat control failure; in this case, replace the thermostat. Alternatively, a Freon leak could be the cause; repair the leak and recharge the system.
S
Sabrina LawrenceSep 1, 2025
How to troubleshoot a Micro Matic MMPP4305-PKG Power Pack when the compressor doesn't start but the fan runs?
- J
  John GordonSep 1, 2025
  If the compressor on your Micro Matic Power Pack doesn't start (no hum), but the fan motor runs, it could be due to a compressor relay or capacitor malfunction; replace the compressor relay or capacitor. Inadequate voltage could also be the cause; measure the voltage across the common and run terminals on the compressor, ensuring it doesn't drop below 90% of the rated voltage. Finally, the compressor itself might have failed and require replacement.
M
montgomerylisaNov 14, 2025
Why is the beer from my Micro Matic MMPP4305-PKG Power Pack warm?
- H
  Harry BerryNov 14, 2025
  Warm beer from your Micro Matic Power Pack can be caused by several issues: * A defective pump. Check the return line in the reservoir for liquid flow. Replace the pump on 125', 250', and 500' units, and also check the motor. Inspect the condition of the key between the pump and motor. * A defective motor (check pump also): Replace the motor. * Trunk lines located in an overheated area: Remove the lines from any hot water pipes or kitchen area with a stove or glass washer. * Trunk lines flooded in PVC chase: Remove lines from PVC, thoroughly dry the PVC, and repair or replace the trunk line as needed. * Uninsulated or poorly insulated lines: Ensure all lines are fully insulated from the cooler into the dispenser, including glycol lines from the power pack into the cooler. * T...

Summary

INSTALLATION AND OPERATION

PLACEMENT GUIDELINES

Guidelines for physically positioning the unit for optimal airflow and accessibility.

INSTALLATION STEPS FOR MMPP4301-EP

Step-by-step instructions for installing the MMPP4301-EP model.

MAINTENANCE

ELECTRONIC TEMPERATURE CONTROL

Details on pre-set thermostat parameters and adjustment for specific models.

CHANGING GLYCOL PUMP

MMPP4301-EP MODEL

Specific instructions for replacing the glycol pump on the MMPP4301-EP.

OTHER MODELS

Procedure for changing the glycol pump on various other models.

REPLACING COMPONENTS

REPLACING MOTOR

Steps for removing and installing a new motor on various models.

REPLACING THERMOSTAT

Instructions for replacing the thermostat in all unit models.

REWIRING THERMOSTAT

Guide for replacing a Dixell thermostat with a Danfoss model.

TROUBLESHOOTING

SPARE PARTS

WIRING DIAGRAMS

WARRANTY

WARRANTY CLAIMS PROCEDURE

Process for initiating and managing warranty claims.

WARRANTY DISCLAIMERS AND LIMITATIONS

Exclusions, limitations of liability, and remedies under the warranty.

Micro Matic MMPP4305-PKG Specifications

General

Amperage	5A
Input Voltage	100-240V AC
Frequency	50/60 Hz
Efficiency	85%
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
