Conditions For Machine Operation
The MR25 is designed for clean water suitable for irrigation. The machine is not designed for
water that includes large pieces of debris or slurry/wastewater conditions.
Start Up Procedure/Operation
1) Push the machine to the desired location. Position the ma-
chine with the sprinkler cart facing the direction to be irrigated.
Insure that the machine is sitting level in order for the tube to
wrap properly.
2) Loosen the black turbine lock knob as shown at the bottom
of the image to the left by turning counter-clockwise. Now the
turbine drive assembly and bracket will slide towards the sprin-
kler cart (as shown by white arrow) to disengage the turbine
drive gears. Re-tighten the knob to hold the turbine drive gear
away from the drum gear. Drum will now spin freely allowing
sprinkler cart to be pulled out.
3) Sprinkler cart may now be pulled out by hand.
IMPORTANT: Pull the sprinkler cart out in a straight line
from the machine to allow the tube to wrap back onto the drum
straight. Never make sharp turns with the polyethylene hose
and always leave one or two wraps on the drum to keep from
pulling the tube off of the drum.
4) Proceed back to the drum and tighten the few loose coils that
are left on the drum by hand. This will ensure that the coils
start wrapping in the correct manner when the drum starts turn-
ing.
Keep remaining wraps tight!!
