**IMPORTANT: ALWAYS PULL CART OUT STRAIGHT AND TIGHTEN LOOSE WRAPS BEFORE START UP!
Keep Wraps Tight! Always Pull Tube Out Straight!
Start Up Procedure/Operation, continued
5) Re-engage the turbine assembly by loosening the black knob
again and sliding the turbine bracket back into place as shown by
white arrow, so that the drive gears mesh. Tighten the black lock
knob again to hold the turbine in place.
IMPORTANT: Before proceeding, try turning the drum by hand to
make sure it is locked in gear. It should be locked and will not turn.
7) Attach supply hose provided to the inlet of the machine and lock
into place as shown
IMPORTANT: MAKE SURE SUPPLY HOSE IS CLEAN AND FREE OF
FOREIGN OBJECTS THAT WOULD PLUG THE TURBINE SYSTEM
OR SHUT OFF VALVE!
6) Open shut off valve by pulling the valve handle and latching
into the open position by swinging the valve latch down and into
position to hold valve open as shown.
IMPORTANT
: PULL VALVE, DO NOT TURN!
NOTE
: DO NOT PULL VALVE OPEN UNDER PRESSURE. OPENING
UNDER PRESSURE WILL DAMAGE VALVE!
VALVE SHOWN IN OPEN, LATCHED POSITION
