Identification Data
The identification plate includes the model and serial number for your machine.
Machine Controls & Components
Shut off valve
(pull valve-do
not turn)
Pressure Gauge
Shut off bar
Shut off valve latch
Grease zerk for inlet seals
(Open small valve to add grease)
Drum Gear (under cover)
Knob to engage/disengage turbine drive
Drain valve (bottom side of gun cart)
Speed control lever
on bypass valve
Water Connection Point (garden hose)
Sprinkler head with
adjustable settings
Pressure Regulator
(allows no more than
60 psi into system)
Turbine Drive & Gear Reduction
