17
During each trip, make sure that the side
stand is always folded correctly.
WARNING
Pre-assembly instructions
Your electric scooter is delivered folded up. Aer having assambled the handle bar on
it, in a few simple steps, it is unfolded and ready to ride. The following explains how to
unfold the scooter.
1. Release the handle bar from the hook located on the rear fender.
2. Pull up the front tube until it is in vertical position. Close the handle until you hear
the click.
3. Plug the connectors. Be careful to do not pinch wires.
4. Assemble the handlebar with a 3 mm Allen key. Tighten all three screws properly.
Scews and tool are included in the box.
