(4) – REMOTE
MiniDIN6 for a PS/2 keyboard or keypad.
(5) – USB: USB B connector for computer connection. Connect a standard USB A-B cable.
(6) – POWER SWITCH
(7) – PADDLE
6.3mm (1/4") stereo female for paddle input.
TIP - DIT
RING - DAH
SHELL - GND
NOTE: The paddle sense can be reversed using Router settings
(8) – CW
RCA jack for CW keying output
TIP - Signal
SHELL - GND
