4
1.STANDBY: Power or standby modes
2.MUTE: Turn volume off. Depress again to activate the sound
3.PC: PC playback source input selection
4. AUX: AUX playback source input selection
5.USB/SD: USB/SD playback source input selections
6.FM:
10.SLEEP: To turn off the system in given time frame Options for 15secs, 30secs, and 45secs
cutoff time frame
11.RESET: Set to factory default settings Master volume set to 20dB TREBLE BASS to
0dB
12.TREBLE: High frequency settings 6dB
13.BASS: L 6dB
14.VOL V 00-60dB
15. P
16.
。
。、
FM radio mode
7.MEMORY: Display FM stored station numbers or current preset number To store a station
scan to your FM radio station first, then depress the MEMORY button on the remote control,
next depress PRE+ or PRE- to your preferred preset number and depress MEMORY button
again to save
8.PRE+/-: Select the preset numbers for memory storage. Depress MEMORY button to save.
Depress RESET to erase all preset stations
9.SCAN+/-: Scan up or down the FM frequency band
and
+/-
ow frequency settings +/-
+/-: olume settings at
revious track
Next track
17. Play or Pause modes
，
.,
：
：
：
Front Panel
USB type A slot
SD card slot
Volume knob
FM Radio
Scanning buttons
Input source selector
Next track / Forward
Play / Pause
Previous / Backward
PowerOn/Off
Illustrations
MODEL: M-700U
AC IN: 220V-240V~ 50Hz 200mA
AMPLIFIED SPEAKER
MADE IN CHINA
RL
ON
OFF
FUSE
T400mAL250V
AC IN
RL
AUDIO INPUT
PC
AUX
AUDIO OUTPUT
High temperature during operation.
Avoid touching back panel
CAUTION: FOR CONTINUED
PROTECTION AGAINST RISK OF FIRE,
REPLACE ONLY WITH SAME TYPE AND
RATING OF FUSE
Rear Panel
3.5mm stereo jack for PC or
Media Players audio input
2RCA jacks for CD player or
Media Players audio input
2RCA jacks to respective
left and right satellites
Power switch On / Off
FUSE socket
AC power cable
