* Includes 9901-2022 sensor and wiring harness.
Table 1 - Carrier Usage Chart
Table 3 - ICP Usage Chart
CARRIER MODEL NUMBER
ECONOMIZER
PART NUMBER
Small Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
ECD-SRT12CB-D2*H
Small Cabinet Legacy units with Central Terminal Board (CTB)
48/50HC, LC, 04-06 48/50TC 04-07
50TCQ 04-07 50HCQ 04-06
50KCQ04-06 48/50KC 04-06
Large Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
48/50FC 08-14
Large Cabinet Legacy units with Central Terminal Board (CTB)
48/50HC, LC, 07-12 48/50TC 08-14
50TCQ 08-14 50HCQ 08-12
ECD-SRT34CB-D2*H
ECD-SRT12CB-D2*H
ECD-SRT34CB-D2*H
X-Large Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
48/50FC 16
Large Cabinet Legacy units with Central Terminal Board (CTB)
ECD-SRT05CB-D2*H
48/50GC 04-06 48/50FC 04-07
50GCQ 04-06 50FCQ 04-07
48/50HC 14 48/50LC 08-12
48/50TC 16 50TCQ 14 50HCQ 12
ECD-SRT05CB-D2*H
ECONOMIZER
PART NUMBER
Small Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
ECD-SRT12CB-D2*H
Small Cabinet Legacy units with Central Terminal Board (CTB)
RGH/RAH 036-060 RGS/RAS 036-072
RHS 036-072 RHX/RHH 036-060
RGX/RAX 036-060
Large Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
Large Cabinet Legacy units with Central Terminal Board (CTB)
RGH/RAH 072-120 RGS/RAS 090-150
RHS 090-150 RHX/RHH 072-120
RGX/RAX 072-120
ECD-SRT34CB-D2*H
ECD-SRT12CB-D2*H
ECD-SRT34CB-D2*H
X-Large Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
Large Cabinet Legacy units with Central Terminal Board (CTB)
ECD-SRT05CB-D2
*H
RGW/RAW 036-060 RGV/RAV 036-072
RGH/RAH 150 RAS/RGS 180
RHS 150 RHH 120
ECD-SRT05CB-D2*H
RGV/RAV 090-150
ICP MODEL NUMBER
RGV/RAV 180
Table 2 - Bryant Usage Chart
ECONOMIZER
PART NUMBER
Small Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
ECD-SRT12CB-D2*
H
Small Cabinet Legacy units with Central Terminal Board (CTB)
581J/551J 04-06
549J/547J/559J/582J 04-06
548J/580J/558J 04-07
Large Cabinet EcoBlue units with Unit Control Board (UCB) &
Vane Axial Fan
Large Cabinet Legacy units with Central Terminal Board (CTB)
581J/551J 07-12
549J/547J/559J/582J 08-12
548J/580J/558J 08-14
ECD-SRT34CB-D2*H
ECD-SRT12CB-D2*H
ECD-SRT34CB-D2*H
X-Large Cabinet EcoBlue units with Unit Control Board (UCB) & Vane Axial Fan
Large Cabinet Legacy units with Central Terminal Board (CTB)
ECD-SRT05CB-D2*H
581K/551K 04-06 559K/582K 04-07
581J/551J14 580J/558J 16 548J 14
549J 12
ECD-SRT05
CB-D2*H
BRYANT MODEL NUMBER
559K/582K 08-14
559K/582K 16
ECONOMIZER
PART NUMBER
QTY CONTENTS
1
Economizer Damper Assembly
with Actuator
1
1
1 Hood Assembly with Top and 2 Sides
1 Hood Divider
1
Aluminum Filter (SRT05 gets 2)
1 Hardware Bag*
* Shipped in control bag for field installation CBOX-CSRT(12/35)B-D2*
Jade 9901-2020 (HW: W7220) Controller
with Attached Harness*
9901-2021 (HW: C7250) Mixed Air Temp
Sensor*
ECD-SRT12CB-D2*H
ECD-SRT34CB-D2*H
ECD-SRT05CB-D2*H
T
able 4 - Package Contents
9901-2021/2022 Outside Air Temp Sensor*
1
Table 5 - Economizer Sensor Usage
APPLICATION
ECONOMIZER WITH OUTDOOR AIR SENSOR
Accessories Required
Outdoor Air
Dry Bulb
9901-2021 outdoor air dry bulb sensor
is field installed on "D2DH" economizer.
Single
Enthalpy
9901-2022 outdoor air enthalpy sensor
is field installed on "D2EH" economizers
Mixed Air
Sensor
9901-2021 provided with economizer and field
installed in blower compartment.
9901-2022-DIFF JC2 this will have to be order
separately*
Differential
Dry Bulb or
Enthalpy
NOTES:
1 - The controller's wiring harness is designed specifically for EcoBlue,
Axiom-Fan, X- Vane units with the Unit Control Board (UCB). If your
unit has the older CTB (Central Terminal Board) or Centrifugal
Supply Blower then you must purchase a different harness.
(MicroMetl P/N 9962-0407 & 9962-0407SAOAEXT, if a NV customer,
then purchase P/N 1002-0407).
2 - If you have a 48/50JC 04-07 unit with System VU, these
controls will not work properly. Please let your distributor
know that you will need an ECD-SRT12CB-D0DB-4 economizer.
