Wireless LAN Access Point Configuration
• IP Address: Select Specify an IP Address. Specify the IP Address and Subnet Mask as
following example.
9 IP Address: 192.168.2.3 (any IP address within 192.168.2.2~192.168.2.254 is available,
do not setup 192.168.2.1)
9 Subnet Mask: 255.255.255.0
8. Reboot the PC. Your PC will now have the IP Address you specified.
1b) Windows XP
1: Click the Start button and select Settings, then click Network Connections. The Network Connections window
will appear.
2: Double-click Local Area Connection icon. The Local Area Connection window will appear.
3: Check your list of Network Components. You should see Internet Protocol [TCP/IP] on your list. Select it
and click the Properties button.
4: In the Internet Protocol (TCP/IP) Properties window, select Obtain an IP address automatically and Obtain
DNS server address automatically as shown on the following screen.
7
