Chapter 4. Installation
12/24
Spray Clip
20:1
Irrigation tube
① Attach the irrigation tube to the straight or
contra-angle handpiece.
Irrigation tube Tube clip
Irrigation tube
Tube clip
Motor cable
Irrigation tube
coolant clip
② Attach the motor cable and irrigation tube
in regular intervals using the coolant clip.
③ Open Irrigation cover by pressing Push button.
④ Put Irrigation tube in the groove.
⑤ Close Irrigation cover.
PUSH
4.3 Installation of irrigation tube
