Operator Maintenance 113
_______________________________________________________________________________________________
_______________________________________________________________________________________________
MICROPLEX Operator’s Manual SOLID F40 Edition 1.1
7.4. Main Charger Replacing
!
After having printed every 50,000 pages A4 landscape the main
charger has to be refurbished.
After having printed 200,000 pages A4 landscape the main charger
has to be replaced.
Turn off the printer and pull the power plug before start working at the
chargers.
1. Open the front cover of the printer.
2. Turn the knob screw of the main charger to loosen it and pull
the main charger out towards you.
Main charge
r
(C1)
Knob screw
3. Replace the new main charger in its original position and
fasten up the knob screw to secure the charger.
4. Close the printer’s front cover.
