Microsemi PD69208 - Installation; Mechanical Assembly; Electrical Assembly; Initial Configuration

PD-IM-7648 Evaluation System - User Guide
Copyright © 2013 Microsemi 18
Rev 1.0 / 25 Dec 13 Analog Mixed Signal Group
1 Enterprise, Aliso Viejo, CA 92656, USA; Phone (USA): (800) 713-4113, (ROW): (949) 221-7100 Fax: (949) 756-0308
5 4BInstallation
This chapter describes the steps required for installing and operating the PD-IM-7648 evaluation system. Some
necessary precautions:
 Verify board's power supply is turned on before peripheral devices are turned on.
 Connect all required peripherals prior to powering board.
 Do not hot swap any components!
 Verify board is well configured prior to turning on power supply.
5.1 14BMechanical Assembly
Step
Action Comments
1
Assemble Line Filter
2
Assemble Power Supply
1.
Mount power supply with 4 screws to enclosure.
2. Mount all required cables.
3
Assemble Motherboard
1. Assemble 5 spacers for DB.
2. Assemble MB with 13 screws to enclosure.
3. Recommended USB communication: install jumper on
J11.
4. Mount all required cables.
4
Assemble Daughterboard
1. Mount DB with 5 spacers to accommodate LED Display
board.
2. Mount all required cables.
5
Assemble LED Display Board
1. Mount LED Display board with 5 screws.
2. Mount all required cables.
3. Mount light pipes as required.
5.2 15BElectrical Assembly
#
Cable Source Destination Comments
1
Internal Line Power Line Filter Power Supply/CN1
2
48V Power Supply/CN2 MB/J6/J7
3
Analog Ground 1
MB/J18
DB/J9
4
Analog Ground 2
MB/J15
DB/J10
5
PoE Domain Signals
MB/J2
DB/J7
6
Host (Switch) Domain Signals
MB/J3
DB/J4
7
Display Data
DB/J1
LED Display/J4
Custom Cable
5.3 16BInitial Configuration
It is highly important to verify that the valuation board is properly configured prior to starting any operation. Refer to
Software GUI User Guide, Catalogue Number 06-0027-056 for detailed information related to software and the GUI
used for Enhance Mode operation.
