PD-IM-7648 Evaluation System - User Guide
Copyright © 2013 Microsemi 2
Rev 1.0 / 25 Dec 13 Analog Mixed Signal Group
1 Enterprise, Aliso Viejo, CA 92656, USA; Phone (USA): (800) 713-4113, (ROW): (949) 221-7100 Fax: (949) 756-0308
Reference Documents
 IEEE 802.3af-2003 Standard, DTE Power via MDI
 IEEE802.3at-2009 Standard, DTE Power via MDI
 PD69208 and PD69200 datasheet, catalogue number DS_PD69208_PD69200
 Application note 211: Designing a PD69208 48-port Enhanced PoE Systems and Layout
Design Guidelines, catalogue PD69208_AN_211
 PD63000 & PD69000/G Serial Communication Protocol User Guide,
catalogue number PD63000_UG
 Software GUI user guide catalog number 06-0027-05
The above documents can be obtained via Microsemi customer support. To access other documents, go to our
website at http://www.microsemi.com/, and under Tech Support\Documentation look up the relevant documents.
