6. Align the C-cover – Properly align the cover to the unit using the front edge alignment posts. Carefully
place the C-cover back onto the unit and shift until the C-cover snaps into place. The top C-cover area under
the display will protrude slightly after C-cover is placed. Press rmly on the top area until you hear a click and
the C-cover attens out.
CAUTION: Ensure that the C-cover is correctly aligned and seated before closing the device. There is the
risk of breaking the display if the device lid is closed before C-cover is aligned.
7. Install C-cover Screws – Close the AB-cover. Turn the unit over and use a 5IP screwdriver to install 4 new
screws to secure the C-cover. Screws should be installed until just snug and seated, and then turned another
45 degrees (1/8 turn) or until fully fastened.
8. Run SDT – Run SDT to ensure all device features and functions operate as expected. Refer to (page 17) for
details on SDT.
9. Install Feet – If SDT tests pass and no further repairs are to be performed on the device, follow steps for
Procedure – Installation (Non-Skid Feet) on page 20.
