18 M1179886
Component Removal and Replacement Procedures
Prior to Device Disassembly:
• Before opening the device, always ensure device is powered off and disconnected from a power supply.
• Always ensure that the work surface is covered with an ESD-safe, soft, non-marring material.
• Work surfaces should be cleaned regularly to ensure debris/abrasive particles are not present.
• Check to make sure that general guidelines and ESD compliance steps are followed prior to opening device.
WARNING: It is recommended that an ESD-safe battery cover be placed across the device to protect the
battery from any physical contact or accidental damage whenever C-cover is removed. Ensure corners
of cover are always aligned with the corners of the device while battery is exposed. If battery cover is
misaligned during activities in any way, re-align before continuing activities.
CAUTION: Check C-cover and device enclosure for any loose articles that may be present inadvertently
on the C-cover or within the device enclosure.
IMPORTANT: Remove rSSD (removable Solid-State Drive) whenever C-cover is removed from device.
rSSD removal disconnects the battery from all device logical components for safety purposes. Refer to
Procedure-Removal (rSSD) section for details.
IMPORTANT: Whenever the rSSD has been removed, powering on the device requires that the rSSD and
C-cover FRUs are installed. Refer to Procedure - Installation (rSSD) section for details.
• FRUs removed from a device under repair during the repair process should be stored in ESD-safe bags and
packaged for return in the same packaging and order that the new replacement part came in.
Current Battery Warning
WARNING: Please note that the battery bears the following warning label. Please heed the information
provided on the label.
B
attery cannot be easily replaced by user
°
°
