29 M1179886
Replacement Process (C-cover Keyboard Fabric type)
Preliminary Requirements
IMPORTANT: Be sure to follow all special (bolded) notes of caution within each process section.
Required Tools and Components
• Tools:
o Software Tool – SDT
o Isopropyl Alcohol Dispense (use only 70% IPA)
o 5IP (Torx plus) driver
o Heavy duty suction cups
o Anti-static wrist strap (1M Ohm resistance)
o Recommended: ESD-safe battery cover (13.5” or 15”)
• Components:
o C-cover (If replacing refer to Illustrated Service Parts List)
(New 5IP screw quantity=4 supplied with component)
Prerequisite Steps:
• Power off device – Ensure device is powered off and disconnected from a power supply.
• General Safety – Check to make sure that general guidelines and ESD compliance steps are followed prior to
opening device. Refer to Prior to Device Disassembly section (page 18) for details.
• Remove feet – Follow steps for Procedure-Removal (Non-Skid Feet) section (page 19).
IMPORTANT: Be sure that all foot adhesive remains have been removed from the bottom device case
foot sockets prior to C-cover screw removal to avoid the risk of stripping out the C-cover screw(s).
